Peri MULTIFLEX - Secondary VT 20; Main 2 x VT 20

34
MULTIFLEX
Secondary Girder: VT 20
Main Girder: 2 x VT 20
0.10 0.12 0.14 0.16 0.18 0.20
4.4 4.8 5.3 5.8 6.3 6.8
0.75 0.625 0.50 0.75 0.625 0.50 0.75 0.625 0.50 0.75 0.625 0.50 0.75 0.625 0.50 0.75 0.625 0.50
0.25 0.50
3.21 3.41 3.67 3.04 3.23 3.48 2.91 3.09 3.33 2.79 2.97 3.20 2.70 2.86 3.09 2.61 2.77 2.99
7.3 7.8 8.4 7.7 8.2 8.9 8.1 8.6 9.3 8.5 9.1 9.8 8.9 9.5 10.2 9.3 9.9 10.7
0.375 0.75
3.21 3.41 3.67 3.04 3.23 3.48 2.91 3.09 3.33 2.79 2.97 3.20 2.70 2.86 3.09 2.61 2.77 2.99
11.0 11.7 12.6 11.6 12.3 13.3 12.2 13.0 14.0 12.8 13.6 14.7 13.4 14.2 15.3 14.0 14.9 16.0
0.50 1.00
3.21 3.41 3.67 3.04 3.23 3.48 2.91 3.09 3.33 2.79 2.97 3.20 2.70 2.86 3.09 2.61 2.77 2.99
14.7 15.6 16.8 15.5 16.4 17.7 16.3 17.3 18.6 17.1 18.1 19.5 17.9 19.0 20.4 18.6 19.8 21.3
0.50 1.25
3.21 3.41 3.67 3.04 3.23 3.48 2.91 3.09 3.33 2.79 2.97 3.20 2.70 2.86 3.09 2.61 2.77 2.99
18.3 19.5 21.0 19.3 20.5 22.1 20.3 21.6 23.3 21.3 22.7 24.4 22.3 23.7 25.6 23.3 24.8 26.7
0.50 1.50
3.21 3.41 3.67 3.04 3.23 3.48 2.91 3.09 3.33 2.79 2.97 3.20 2.70 2.86 3.09 2.61 2.77 2.99
22.0 23.4 25.2 23.2 24.7 26.6 24.4 25.9 27.9 25.6 27.2 29.3 26.8 28.5 30.7 27.9 29.7 32.0
0.50 1.75
3.21 3.41 3.67 3.04 3.23 3.48 2.91 3.09 3.33 2.79 2.97 3.20 2.70 2.86 3.09 2.61 2.77 2.99
25.7 27.3 29.4 27.1 28.8 31.0 28.5 30.3 32.6 29.9 31.7 34.2 31.3 33.2 35.8 32.6 34.7 37.3
0.50 2.00
3.21 3.41 3.67 3.04 3.23 3.48 2.91 3.09 3.33 2.79 2.97 3.20 2.70 2.86 3.09 2.61 2.77 2.99
29.3 31.2 33.6 30.9 32.9 35.4 32.5 34.6 37.3 34.1 36.3 39.1 35.7 38.0 40.9 37.3 39.6 42.7
0.22 0.24 0.25 0.26 0.28 0.30
7.3 7.8 8.0 8.3 8.8 9.3
0.75 0.625 0.50 0.625 0.50 0.40 0.625 0.50 0.40 0.625 0.50 0.40 0.625 0.50 0.40 0.625 0.50 0.40
0.25 0.50
2.53 2.69 2.90 2.62 2.82 3.04 2.59 2.79 3.00 2.56 2.75 2.97 2.50 2.69 2.90 2.44 2.63 2.84
9.7 10.3 11.1 10.7 11.5 12.4 10.9 11.7 12.6 11.1 12.0 12.9 11.5 12.4 13.3 11.9 12.8 13.8
0.375 0.75
2.53 2.69 2.90 2.62 2.82 3.04 2.59 2.79 3.00 2.56 2.75 2.97 2.50 2.69 2.90 2.44 2.63 2.84
14.5 15.5 16.7 16.1 17.3 18.6 16.4 17.6 19.0 16.6 17.9 19.3 17.2 18.6 20.0 17.8 19.2 20.7
0.50 1.00
2.53 2.69 2.90 2.62 2.82 3.04 2.59 2.79 3.00 2.56 2.75 2.97 2.50 2.69 2.90 2.44 2.63 2.84
19.4 20.6 22.2 21.4 23.1 24.8 21.8 23.5 25.3 22.2 23.9 25.8 23.0 24.7 26.7 23.7 25.6 27.5
0.50 1.25
2.53 2.69 2.90 2.62 2.82 3.04 2.59 2.79 3.00 2.56 2.75 2.97 2.50 2.69 2.90 2.44 2.63 2.84
24.2 25.8 27.8 26.8 28.8 31.1 27.3 29.4 31.6 27.7 29.9 32.2 28.7 30.9 33.3 29.7 32.0 34.4
0.50 1.50
2.53 2.69 2.90 2.62 2.82 3.04 2.59 2.79 3.00 2.56 2.75 2.97 2.50 2.69 2.90 2.44 2.63 2.84
29.1 30.9 33.3 32.1 34.6 37.3 32.7 35.2 37.9 33.3 35.9 38.6 34.5 37.1 40.0 35.6 38.3 41.3
0.50 1.75
2.53 2.69 2.90 2.62 2.82 3.04 2.59 2.79 2.98 2.56 2.75 2.90 2.50 2.69 2.73 2.44 2.59 2.59
33.9 36.1 38.9 37.5 40.4 43.5 38.2 41.1 44.0 38.8 41.8 44.0 40.2 43.3 44.0 41.5 44.0 44.0
0.50 2.00
2.53 2.69 2.87 2.62 2.69 2.69 2.59 2.61 2.61 2.53 2.53 2.53 2.39 2.39 2.39 2.27 2.27 2.27
38.8 41.2 44.0 42.8 44.0 44.0 43.6 44.0 44.0 44.0 44.0 44.0 44.0 44.0 44.0 44.0 44.0 44.0
Prop Spacing c [m]
Slab Thickness
d [m]
Load
q* [kN/m
2
]
Sec. Girder
Spacing a [m]
Prop Spacing c [m]
Slab Thickness
d [m]
Load
q* [kN/m
2
]
Sec. Girder
Spacing a [m]
Cantilever e [m]
Cantilever e [m]
