Peri MULTIFLEX - PEP Ergo D Prop Loads

37
PEP Ergo D-150
L = 0.98 – 1.50 m
PEP Ergo D-250
L = 1.47 – 2.50 m
PEP Ergo D-350
L = 2.26 – 3.50 m
PEP Ergo D-400
L = 2.51 – 4.00 m
PEP Ergo D-500
L = 3.26 – 5.00 m
1.00 30.0 30.0
1.10 30.0 30.0
1.20 30.0 30.0
1.30 30.0 30.0
1.40 28.4 30.0
1.50 26.4 30.0 35.0 35.0
1.60 35.0 35.0
1.70 32.8 35.0
1.80 30.7 35.0
1.90 29.1 35.0
2.00 28.1 35.0
2.10 27.2 35.0
2.20 26.4 34.0
2.30 25.7 32.3 40.0 40.0
2.40 24.2 29.4 40.0 40.0
2.50 22.4 26.2 40.0 40.0
2.60 37.8 40.0 40.0 40.0
2.70 35.1 40.0 40.0 40.0
2.80 33.0 40.0 40.0 40.0
2.90 31.1 40.0 40.0 40.0
3.00 29.6 40.0 40.0 40.0
3.10 28.1 38.6 37.7 40.0
3.20 26.9 34.7 35.6 40.0
3.30 25.0 31.5 33.7 40.0 40.0 40.0
3.40 23.1 28.6 32.3 40.0 40.0 40.0
3.50 21.2 25.8 30.7 39.3 40.0 40.0
3.60 28.6 35.9 40.0 40.0
3.70 26.7 32.9 40.0 40.0
3.80 24.9 30.2 40.0 40.0
3.90 23.1 27.8 40.0 40.0
4.00 21.4 25.3 40.0 40.0
4.10 39.0 40.0
4.20 36.3 40.0
4.30 33.8 39.0
4.40 31.6 36.7
4.50 29.6 34.3
4.60 27.8 32.1
4.70 26.1 30.1
4.80 24.5 28.2
4.90 23.0 26.4
5.00 21.4 24.7
Permissible Prop Load [kN] according to Type Test
Extension Length [m]
Outer Tube
Bottom
Inner Tube
Bottom
Outer Tube
Bottom
Inner Tube
Bottom
Outer Tube
Bottom
Outer Tube
Bottom
Outer Tube
Bottom
Inner Tube
Bottom
Inner Tube
Bottom
Inner Tube
Bottom
Slab Props
PEP Ergo D
Note:
Q
PERI PEP Ergo D-150, PEP Ergo D-250, PEP Ergo D-350, PEP Ergo D-400 and
PEP Ergo D-500 props fulfil Prop Class D load-bearing capacity requirements of
DIN EN 1065.
Q
In addition, the PEP Ergo D-250 prop fulfils Prop Class B requirements as
stipulated in DIN EN 1065.
Q
General Building Inspectorate Approval Z-8.311-934 for PERI PEP Ergo D-150
and PEP Ergo 250.
Q
General Building Inspectorate Approval Z-8.311-941 for PERI PEP Ergo D-350,
PEP Ergo D-400 and PEP Ergo D-500.
