Peri MULTIFLEX - PEP 20 Prop Loads

40
Slab Props
PEP 20
*For the N props, a use of the inner
tube at the bottom is only possible in
connection with PERI slab tables or
SKYDECK (bolted head).
PEP 20 N 260*
L = 1.51 – 2.60 m
PEP 20-300
L = 1.71 – 3.00 m
PEP 20-350
L = 1.96 – 3.50 m
PEP 20-400
L = 2.21 – 4.00 m
PEP 20-500
L = 2.71 – 5.00 m
1.60 35.0 35.0
1.70 35.0 35.0
1.80 35.0 35.0 36.4 36.4
1.90 35.0 35.0 36.4 36.4
2.00 33.5 35.0 36.1 36.4 36.4 36.4
2.10 31.9 35.0 33.2 36.4 36.4 36.4
2.20 30.9 35.0 31.4 36.4 36.4 36.4
2.30 29.8 35.0 29.9 36.4 36.4 36.4 36.4 36.4
2.40 28.6 35.0 28.7 36.4 36.4 36.4 36.4 36.4
2.50 27.1 32.9 27.7 36.4 36.4 36.4 36.4 36.4
2.60 24.8 29.4 26.9 36.3 34.8 36.4 36.4 36.4
2.70 25.7 32.7 33.4 36.4 36.4 36.4
2.80 24.0 29.3 32.1 36.4 36.4 36.4 36.4 36.4
2.90 22.3 26.5 31.1 36.4 36.4 36.4 36.4 36.4
3.00 20.5 23.9 30.1 36.4 36.4 36.4 36.4 36.4
3.10 28.3 35.7 34.6 36.4 36.4 36.4
3.20 26.5 32.5 33.5 36.4 36.4 36.4
3.30 24.8 29.7 32.1 36.4 36.4 36.4
3.40 23.1 27.2 30.5 36.4 36.4 36.4
3.50 21.3 24.8 28.7 34.9 36.4 36.4
3.60 26.9 32.1 36.4 36.4
3.70 25.3 29.8 36.4 36.4
3.80 23.7 27.6 36.4 36.4
3.90 22.3 25.5 36.4 36.4
4.00 20.7 23.5 35.3 36.4
4.10 33.3 36.4
4.20 31.5 36.4
4.30 29.8 35.0
4.40 28.2 32.9
4.50 26.8 30.8
4.60 25.3 28.9
4.70 24.1 27.2
4.80 22.8 25.7
4.90 21.5 24.1
5.00 20.3 22.1
Permissible Prop Load [kN] according to the Type Test
Extension Length [m]
When using PERI slab tables, the per-
missible load for all PEP 20 props is a
minimum of 30 kN over the entire ex-
tension lengths due to the clamping in
the Table Swivel Head or UNIPORTAL
Head.
All PEP 20 props correspond to Class D
of DIN EN 1065, i. e. the permissible
load for all extension lengths is a mini-
mum of 20 kN.
Outer Tube
Bottom
Inner Tube
Bottom
Outer Tube
Bottom
Inner Tube
Bottom
Outer Tube
Bottom
Inner Tube
Bottom
Outer Tube
Bottom
Inner Tube
Bottom
Outer Tube
Bottom
Inner Tube
Bottom
