PerkinElmer LAMBDA 265 Installation Instructions

09931228D
2
gs
Dimensions and Specifications
Dimensions of Peltier Controller
Physical Characteristic Specification
Power
100-240 VAC, 50/60 Hz, 300W, Free Voltage
Temperature Range
-5 to 100°C (Maximum Internal Temperature)
Maximum Ambient Operating Temperature 40°C
Dimensions
310(W) x 410(D) x 275(H) mm
Weight
20.0 Kg
Coolant Volume
2 L
N
2
Gas Pressure Limit
100 psi (6
.9 bar)
Liquid Cooling System
Magnetic Stirrer Control Available
Emer
gency Power Off Switch Available
Specifications of Peltier Controlled Single Cell
Physical Characteristic Specification
Dimensions 65(W)x240(D)x114(H)mm
Weight 1.4 Kg
Temperature Accuracy ±0.15°C
Temperature Precision ±0.1°C
Temperature Stability ±0.1°C
Ramping Time (from 25 to 100°C)
4 minutes

PerkinElmer LAMBDA 265 Specifications

General

Brand	PerkinElmer
Model	LAMBDA 265
Category	Measuring Instruments
Language	English
