Perkins 103-06 - SECTION VI Electrical Systems; Alternator Operation and Testing

E0103
Speed(rpm)
SECTION VI
Electrical Systems
Alternator
N.B. (Perama M25/M30 Lucas A127 - see
Section 10).
- Specification and Performance
103-09/10/Perama M25/M30
Type G P9150
Direction of rotation Clockwise
(Viewed from pulley)
Speed 1300-6000rpm
Charging capacity 15-16.5A at 14V
at 5000rpm
Minimum charging
speed
Less than 1600rpm
(at 13V)
Regulator RS5101
Part number 185046160
18
16
14
12
10
8
6
4
2
0
103-06
Type GP8146
Direction of rotation Clockwise
(Viewed from pulley)
Speed 1600-5600rpm
Charging capacity 14-15Aat14V
at 5200rpm
Minimum charging
speed
Regulator RS5101
Part number 185046160
- Construction
The alternator consists of the stator (armature
coil and coil plate) and the flywheel which
contain ferrite magnets.
Q 40
w
C D 30
6 20
0 10
z 0
Revolution N(
rpm)
PB119
PB118
Upper limit
Lower limit
E
B
O
C
"
FM
1
2 3 4 5 6 x 10
3
