Perkins 1104E - Page 14

14 SEBU8121
Product Information Section
Model Views
(1) Fuel lines
(2) Fuel primin
g pump
(3) Fuel filter
(4) M achine int
erface connector (MIC)
(5) S peed/timin
gsensor
(6) Electronic f
uel injection pum p
(7) Engine oil pr
essure se nsor
(8) Engine oil f
ilter
(9) Water pump
(10) Crankshaf
t pulley
(11) Alternato
r
(12) Engine cool
ant temperature sensor
(13) Voltage loa
d protection modu le
(14) Electronic
control module ( ECM )
g01131701
Illustration 9
Right side view of the 1104 engine
Typical example of the 1104 engine
(1) Exhaust elbow
(2) Turbocharger
(3) Wastegate actuator
(4) S tarter motor
(5) F lywheel housing
