34 KENR9126
Troubleshooting Section
Exhaust Gas Temperature Sensor
Installation S
tatus
An exhaust gas temperature sensor is an optional
sensor input.
Programming the “Exhaust Gas
Temperature Sensor Installation Status” parameter
to “Enabled” notifies the ECM that an exhaust gas
temperature
sensor input is present on pin J1:54.
When this parameter is programmed to “Enabled”
and the exhaust gas temperature sensor goes above
the measure
d level, an “E194-1” or “J173-15” event
code will be displayed.
Table 13
Value
Default
Installed
Not Installed
Not Insta lled
Transmission Oil Pre ssure Sensor
Installation Status
A transmission oil pressure sensor is an optional
sensor input. Programming the “Transmission Oil
Pressure Sensor Installation Status” parameter to
“Enabled” notifies the ECM that a transmission oil
pressure sensor input is present on pin J2:54. When
this parameter is programmed to “Enabled” and the
transmission oil pressure sensor goes above the
measured level, an “E113-1” or “J127-15” event code
will be displayed.
Table 14
Value Default
Installed
Not Installed
Not Insta lled
Transmission Oil Temperature Sensor
Installation Status
A transmission oil temperature sensor is an optional
sensor input. Programming the “Transmission Oil
Temperature Sensor Installation Status” parameter
to “Enabled” notifies the ECM that a transmission oil
temperature sensor input is present on pin J2:49.
When this parameter is programmed to “Enabled”
and the transmission oil temperature sensor goes
above the measured level, an “E877-1” or “J177-15”
event code will be displayed.
Table 15
Value Default
Installed
Not Installed
Not Insta lled
Fuel P ressure Sensor Installation Status
A fuel pressure sensor is an optional sensor input.
Programming the “Fuel Pressure Sensor Installation
Status” param
eter to “Enabled” notifies the ECM
that a fuel pressure sensor input is present on pin
J1:56. When this parameter is programmed to
“Enabled” an
d the fuel pressure sensor falls below
the measured level, an “E198-1” or “J94-17” event
code will be displayed.
Table 16
Value Default
Installed
Not Installed
Not Installed
Fuel Level Sensor Installation Status
A fuel level sensor is an optional sensor input.
Programming the “Fuel Level Sensor Installation
Status” parameter to “Enabled” notifies the ECM
that a fuel level sensor input is present on pin J2:41.
When this parameter is programmed to “Enabled”
and the fuel level sensor falls below the measured
level, an “E119-1” or “J96-17” event code will be
displayed.
Table 17
Value Default
Installed
Not Installed
Not Installed
