DESCRIPTION OF THE VEHICLE
1. Instrument panel
2.
Utility hanger
3. Lock (Fuel tank flap/Storage compartment)
4. Fuel tank
5. Rider saddle
6. Passenger backseat
7. Grab handle
8. Kick starter
1
9. Central stand
10. Folding passenger footrests
11. Lateral stand
12. Left brake lever
13. Brake fluid level
14. Right brake lever
15. Throttle
16. Ignition switch / Opening of the saddle
17. 12V accessory socket / USB socket
1
18. Engine oil level
19. Battery/Fuses
20. Saddle storage compartment
1. Depending on model
12
13
2
10
19
20
6 7
5
4
17
15
16
3
911 8
18
10
1
14
13
7
