Reproduction or translation, even partial, is forbidden without the written consent of Peugeot Motocycles 15/27
FR
GB
DE
IT
ES
NL
GR
SE
PT
FI
DK
ACCESSORY
FRONT LUGGAGE CARRIER
REAR LUGGAGE CARRIER
TOP CASE
Opening the top box:
- Insert the key into the lock.
- Turn the key to the right in the lock and push the
button (A).
Open the top box.
Closing the top box:
- Press on the locking flap (B) and turn the key to the left
in the lock.
- Remove the key.
Removing the top box:
- Insert the key into the lock towards the right.
- Turn the key in the lock and push the button (C)
- Remove the top box and remove the key from the lock
to avoid breaking it.
The front luggage carrier can bear a
maximum load of 3 kg.
The rear luggage carrier can bear a
maximum load of 6 kg.
To not place luggage on it that is too
bulky and may impair the lighting and
steering.
Do not exceed the maximum
recommended load for each luggage
carrier.
Attach luggage firmly to the vehicle, even
over a short distance.
The top box is delivered with 2 keys.
The maximum permissible load for the top
box is 3 kg.
A
B
C

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the PEUGEOT DJANGO 50 2021 and is the answer not in the manual?

PEUGEOT DJANGO 50 2021 Specifications

General IconGeneral
Engine TypeSingle cylinder, 4-stroke
Engine Stroke4
Displacement49.9 cc
Cooling SystemAir-cooled
Rear SuspensionHydraulic shock absorber
Tires (Front)120/70-12
Seat Height770 mm
Width710 mm
Height1, 150 mm
Top Speed45 km/h
TransmissionAutomatic
Front SuspensionTelescopic fork
Brakes (Front)Disc
Brakes (Rear)Drum
Fuel Tank Capacity8.5 L
Length1925 mm
Fuel SystemElectronic fuel injection
