Safety
Do not operate the machine
without belt guards 4 and 5!
Danger of injury by the revolving
V-belt!
1 - 5
Fig.1 - 02
Fig. 1 - 03
4
5
3
Do not operate the machine
without tilt-back safeguard 3!
Danger of crushing between
upper part and table top!

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Pfaff 1245 and is the answer not in the manual?

Pfaff 1245 Specifications

General IconGeneral
TypeIndustrial Sewing Machine
Stitch TypeLockstitch
Needle System134-35
Feed MechanismTriple Feed
ApplicationMedium to Heavy Material
