Pfaff 4874 - Adjustment of Threads Take up Lever for Top Cover and Deco Cover

ADJUSTMENT OF THREAD TAKE UP LEVER FOR TOP COVER
AND DECO-COVER.
25
In order to obtain good stitching result especially for the Top-Cover and DECO-Cover, main-
tain well Thread take up lever "A".
For this purpose, check the distance of both "a" and "b" and if both are not equal, adjust the
shape of Thread take up lever(A) by hand work with bending it in the directionof arrow
( ) upto resulting to have equal distance at the "a" and "b".
A
a=b
a
b
