Pfaff 591

27
Raise the presser bar lifter.
Adjust the presser bar 1 (screws 2) according to the requirement. Make sure that the
roller presser is parallel to the feed wheel.
1.04.18 Clearance between roller presser and feed wheel
Requirement
When the presser bar lifter is raised, the clearance between the roller presser and the
feed wheel must be 7 mm.
Fig. 1 - 18
1
2
61-040
7 mm
Adjustment
