Pressure of roller presser
Requirement
The material must be f
ed smoothly
. No pressure marks should be visible on the material.
Adjust roller presser pressure with scre
w
1
according to the
requirement
.
Fig.
1
-
28
1
+
-
Screw
1
is located under a cover.
If the presser foot pressure is low, the lowering speed of the presser foot can
be increased with parameter
„202“
, see
Chapter 1.08 Parameter settings
.
Adjustment
36
38
