6
1 Adjustment
Please observe all notes from Chapter 1 Safety of the instruction manual!
In particular care must be taken to see that all protective devices are refi tted
properly after adjustment, see Chapter 1.06 Danger warnings of the instruc-
tion manual!
If not otherwise stated, the machine must be disconnected from the electrical
power supply. Danger of injury due to unintentional starting of the machine!
Notes on adjustment
All following adjustments are based on a fully assembled machine and may only be carried
out by expert staff trained for this purpose.
Machine covers, which have to be removed and replaced to carry out checks and adjust-
ments, are not mentioned in the text.
The order of the following chapters corresponds to the most logical work sequence for
machines which have to be completely adjusted. If only specifi c individual work steps are
carried out, both the preceding and following chapters must be observed.
Screws, nuts indicated in brackets ( ) are fastenings for machine parts, which must be
loosened before adjustment and tightened again afterwards.
1.01 Tools, gauges and other accessories
1 set of screwdrivers with blade widths from 2 to 10 mm
1 set of open-ended wrenches with opening sizes from 7 to 13 mm
1 set of allen keys from 1.5 to 6 mm
1 clamp (Order No. 08-880 137-00)
1 metal rule (Order No. 08-880 218-00)
1 gauge (Order No. 08-880 136-01)
Sewing thread and test material
1.02 Abbreviations
TDC = top dead center
BDC = bottom dead center
1.03 Explanation of the symbols
In this adjustment manual, symbols emphasize operations to be carried out or important in-
formation. The symbols used have the following meaning:
Note, information
Service, repair, adjustment, maintenance
(work to be carried out by qualifi ed staff only)
Adjustment
