Pfaff 591

46
1
.05.07 Knife position
Requirement
When the edge trimmer is engaged, the knife should rest lightly on the needle plate in-
sert, but no whistling sound should occur during trimming.
PFAFF 571
Adjust screw 1 (screw 2) according to the requirements.
Carry out a cutting test and repeat adjustment if necessary.
PFAFF 591
Adjust knife 3 (screw 4) according to the requirements.
Carry out a cutting test and repeat adjustment if necessary.
Fig. 1 - 37
1
2
61-055
3
4
Adjustment
