5-7
Top Cover Stitch
When attaching the thread guide, make
sure that the holder for the top/deco
switch lever is fully seated in slot A. Now
push the thread guide device back as far as
it will go until you hear it click into place.
To remove it, press handle B down against
C (the part where the triangle thread
guide is attached). Pull it gently towards
you and out of the holder.
When you press the memory selection
button P once, the program memory
opens. The thread tension values appear
beside the program number in the display.
First thread the purple thread tension for
the cover-stitch looper, followed by the
blue, green and red thread tensions for the
needles.
You can also refer to the threading
diagram behind the front cover. Finally,
you must thread the blue top cover thread.
Threading the cover-stitch looper
Turn the hand wheel towards you until the
cover-stitch looper (33) is as far to the right
as possible.
33
B
C
