14
1
2
4
3
Presser foot pressure adjustment
The presser foot pressure is pre-adjusted for
fabrics of medium (standard) thickness.
Adjustment is necessary only when you work
on very thin or very thick fabrics.
Accordingly, sew thinner fabrics with less
pressure and thicker fabrics with more
pressure. Increase or decrease the pressure
of the presser foot by turning the adjustment
screw in the direction as shown.
Tighten Loosen
Thread tension adjustment
Adjust thread tension to suit the type of
fabric and size of thread used. As the number
on the thread tension discs increases, the
thread tension becomes tighter.
1. Correct tension
Lower looper thread and upper looper
thread should be well balanced with same
tension (both looper threads should cross at
the edge of the fabrics).
Needle threads should not be too loose or
too tight, but equally balanced tension.
Top side
Underside
