6
1-3 Connecting the foot control
and the electrical connection
Connect the foot control and the electrical
connection.
Before plugging your machine, be sure that
the voltage is same as that of your machine.
(indicated on the plate on the back of the
machine).
Note: Specifications vary from country to
country.
Turn on the power and light switch.
Always turn off the switch and unplug the
machine when not in use; changing needles,
presser foot, or needle plate; or servicing/
cleaning the machine.
The harder you press the foot control, the
faster the machine runs.
When the power switch is turned off, the
machine will not operate even with pressure
on the foot control.
• Electronic foot control
(for USA/Canada only)
This foot control gives full penetration power
even at slow speed for all sewing needs.
For the USA and Canada
This sewing machine has a polarized
plug (one blade wider than the other).
To reduce the risk of electric shock, this
plug is intended to fit in a polarized
outlet only one way. If the plug does not
fit fully in the outlet, reverse the plug.
If it still does not fit, contact a qualified
electrician to install the proper outlet.
Do not modify the plug in any way.
• Use foot control type YC-482T for USA/
Canada and YC-190 for other countries with
overlock machine Model 4764.
