1. Summary
1-1 Parts of hobbylock 4764
1 Spool pin
2 Presser foot lift
3 Thread take up lever
4 Adjustment knob for presser foot
pressure
5 Thread guides
6 Telescopic thread guide
7-1 Left needle thread tension
7-2 Right needle thread tension
7-3 Thread tension/upper looper
7-4 Thread tension/lower looper
8 Front panel
9 Swivel table
10 Seam length adjustment knob
11 Standard presser foot
12 Seam width adjustment knob
13 Upper blade
14 Front cover
15 Handwheel
(right side of the machine)
16 Differential feed dial
17 Light bulb cover
To Next Page
