Operating Manual | Attachment and Installation Cooling Units | Multi Controller (MC) – 400 / 460 V, 3~ | 086100124 24/76
Value Description
Type Unit type
P/N Part number
S/N Serial number
Urated Rated voltage/frequency
Irated Nominal current
Istart Starting current
gG Fuse
Evap. FLA / HP Evaporator fan Full Load Amps / horse power
Full-load current consumption of the evaporator fan/capacity of the evaporator fan in HP
Cond. FLA / HP Condenser fan Full Load Amps / horse power
Full-load current consumption of the condenser fan/capacity of the condenser fan in HP
Comp. RLA / LRA Compressor Rated Load Amps (RLA) / Locked Rotor Amps (LRA)
Nominal current of the compressor/blocking current of the compressor
A35 / A35
A50 / A35
External ambient temperature/temperature in the switch cabinet
Pel Electric power consumption
Qsens Cooling capacity
EER Ratio between power consumption and emitted cooling capacity (Energy Efficiency Ratio)
MOP* Maximum Overcurrent Protection
MCA* Minimum Circuit Ampacity
Pmax Refrigerant pressures
GWP Global warming potential (Global Warming Potential) of the refrigerant
CO2e CO
2
equivalent of the refrigerant filling
Tab. 5: Type plate data
* Data for UL-approved units on the design of the protection (MOP) and cable cross-sections (MCA).
