Operating Manual | Attachment and Installation Cooling Units | Multi Controller (MC) – 400 / 460 V, 3~ | 086100124 28/76
3.7.3 Dimensions
Designation Unit Model DTI / DTS 6401
Height
mm DTI: 1537
DTS: 1547
Width
mm 485
Depth with cover (standard)
mm 278
Installation depth DTI
mm 120
Weight
kg DTI: 63
DTS: 66
Installation attitude
— Vertical
Unit construction
— Standard: Steel sheet
Option: With stainless-steel cover
Tab. 11: Dimensions and weight model DTI / DTS 6401
Designation Unit Model DTI / DTS 6501
Height
mm DTI: 1537
DTS: 1547
Width
mm 485
Depth with cover (standard)
mm 278
Installation depth DTI
mm 120
Weight
kg DTI: 69
DTS: 72
Installation attitude
— Vertical
Unit construction
— Standard: Steel sheet
Option: With stainless-steel cover
Tab. 12: Dimensions and weight model DTI / DTS 6501
3.7.4 Other unit data
Designation
Anti-corrosion protection Standard: Galvanized, electrostatically powder-
coated (200°C)
Variant: Stainless-steel cover (material 1.4301, grounded)
Housing protection type (according to EN 60529) When used as intended:
• IP 55 internal – against the switch cabinet.
• IP 24 internal – against the environment.
