ENG
Operating Manual | Attachment and Installation Cooling Units | Multi Controller (MC) – 400 / 460 V, 3~ | 086100124 27/76
3.7.2 Electrical data
Designation Unit Model DTI / DTS 6401
Rated voltage */** 50 Hz
V 400 V, 2~
60 Hz
V 460 V, 2~
Rated frequency *
Hz 50/60
Functional area
— DIN IEC 60038
Power consumption * A35 / A35 P
el
50 Hz
W 727
P
el
60 Hz
W 911
Power consumption * A50 / A35 P
el
50 Hz
W 848
P
el
60 Hz
W 1052
Nominal current * I
nom
50 Hz
A 2.2
I
nom
60 Hz
A 2.1
Start-up current * I
Start max
50 Hz
A 7.7
I
Start max
60 Hz
A 8.1
MOP (Maximum Overcurrent Protection)***
A 15.0
MCA (Minimum Circuit Ampacity)***
A 2.9
Internal control fuse for transformer. Category
“Class CC”, slow-blow, suitable for transformer
protection.
F2, F3
A 3.0
Tab. 9: Electrical data model DTI / DTS 6401
Designation Unit Model DTI / DTS 6501
Rated voltage */** 50 Hz
V 400 V, 3~
60 Hz
V 460 V, 3~
Rated frequency *
Hz 50/60
Functional area
— DIN IEC 60038
Power consumption * A35 / A35 P
el
50 Hz
W 929
P
el
60 Hz
W 1140
Power consumption * A50 / A35 P
el
50 Hz
W 1084
P
el
60 Hz
W 1309
Nominal current * I
nom
50 Hz
A 2.3
I
nom
60 Hz
A 2.4
Start-up current * I
Start max
50 Hz
A 12.0
I
Start max
60 Hz
A 13.0
MOP (Maximum Overcurrent Protection)***
A 15.0
MCA (Minimum Circuit Ampacity)***
A 3.3
Internal control fuse for transformer. Category
“Class CC”, slow-blow, suitable for transformer
protection.
F2, F3
A 3.0
Tab. 10: Electrical data model DTI / DTS 6501
* Data on the type plate.
** In case the rated voltage changes, adapt the upstream fuse, see "Adapting the unit to the mains voltage", Page 48.
*** Data for UL-approved units on the design of the protection (MOP) and cable cross-sections (MCA).
