Note
Tip
Check a key point on the graphic.
Apply the stated tightening torque.
Respect the chronological order of operations and/or assembly/disassembly direction.
Correct, right choice.
Incorrect, wrong choice.
1.3.3 Labels
I/O Main switch/Circuit breaker
INPUTS/OUTPUTS Inputs/Outputs communication interface connector
SERIAL 9-pin D-Sub RS-232 serial link connector
1 This label indicates that the product has been certified compliant with quality con-
trol upon leaving the factory.
2 This label indicates that some of the internal parts are electrically live and could
cause electrical shock in case of contact.
● Do not use the product if the main power supply cable is not earthed.
● Disconnect the main power supply cable from the product before servicing
the product.
3 This label indicates that the product must be handled using the devices identified
by this label.
● Comply with the rules for moving the equipment, taking weight and dimen-
sions into account.
4 This label indicates that the product is subject to regulations for the treatment of
electrical and electronic equipment waste (refer to the EC declaration of conform-
ity for the product).
5
1 2
5 6
7
3 4
98 avenue de Brogny F-74000 ANNECY
Kg
P/N :
S/N :
V Hz W
8
Made in France
Product rating plate.
1 Weight 5 Part Number
2 Use voltage 6 Description
3 Use frequency 7 Serial number
4 Maximum power consumption 8 Date of manufacture
6 This label indicates that some of the internal parts are electrically live and could
cause electrical shock in case of contact.
● Disconnect the main power supply cable from the product before removing
the cover.
-
FR AEOF 00165062 - assurance qualité / quality control
This label guarantees to the user that the product packaging has not been
opened since leaving the factory.
-
PRODUIT PERSONNALISE
CUSTOMIZED PRODUCT
This label indicates that the product has been customized at the customer’s re-
quest.
- This label indicates the grounding point on the product.
About this manual
5/36
