Pfeuffer Sample cleaner MLN - Page 16

Delivery, transport and storage
16 | 38
Operating instructions sample cleaner MLN | Revision 3
Type
Weight
Handling
MLN
approximately 55 kg
Operator must provide for safe transportation
Unpacking
Figure 4: Unpacking
In order to avoid damages to the casing and other components,
 open the packaging
 lift the sample cleaner out of the carton with the help of at
least four persons
 bring the sample cleaner to the installation site using a
pushcart.
Packaging for return delivery
 If possible, use the original packaging and original packaging material. If both are unavailable, engage
a packaging company with skilled personnel.
 Place the carton on a transport pallet (refer to the weight specification). Put the sample cleaner MLN
back into the carton with the help of at least four persons.
Figure 5: Lifting with the help of four persons
 Place the Styrofoam block next to the sample cleaner MLN to fill the hollow space.
Figure 6: Packaging for return transport
 Seal the carton and fasten the sample cleaner MLN on the transport pallet.
