Pfeuffer Sample cleaner MLN - Bottom Sieve (Sand Sieve)

Operation
Revision 3 | Operating instructions sample cleaner MLN
27 | 38
7.4.2 Bottom sieve (sand sieve)
 Pull the sieve to be changed.
 Slide the new sieve on the sieving tray till the stop. It might have to be slightly lifted.
 Pay attention to the mounting position; refer to figure 17.
Figure 17: Sand sieve - mounting position
Dimensions: 300x350 mm
Item
Name
1
Engraved number
2
Surface not stamped
 Firmly re-clamp all the sieves on the holders using the tension springs.
