PFT RITMO L plus - 6.6 Compressor DT4.8; 6.7 Operating requirements; 6.8 Connection values for water; 7 Sound power level

Mixing pump RITMO L plus FC-230V Overview – Operation
Sound power level
2020-11-09 11
6.6 Compressor DT4.8
Specification Value Unit
Compressor output 0.080 Nm³/min
6.7 Operating requirements
Ambient conditions
Specification Value Unit
Temperature range 2 - 45 °C
Relative humidity (maximum) 80 %
Operating period
Specification Value Unit
Maximum continuous operating period
8
hours
6.8 Connection values for water
Fig. 1: Water connection
Specification Value Unit
Operating pressure, min. 2.5 bar
Connection 1/2 inches
7 Sound power level
Guaranteed sound power level LWA 78 dB (A)
8 Vibrations
Weighted effective acceleration value to which the upper limbs are exposed = < 2.5 m/s²
9 EMC test
The machine has been EMC tested and complies with the strict requirements of EMC Directive filter class B.
The control box is equipped with a line filter.
