Mixing pump RITMO L plus FC-230V Overview – Operation
Assembles RITMO L plus
14 2020-11-09
13.2 View from rear RITMO L plus
Fig. 6: View from rear
1. Tool box.
2. Control box.
3. Mains connection 230V.
4. Air compressor DT4.8.
5. Water manifold.
6. Dummy plug / remove control
cable connection.
7. Water flowmeter (water manifold).
14 Assembles RITMO L plus
14.1 Gear motor with material hopper and pump unit
Fig. 7: Material hopper assembly
The mixing pump PFT RTIMO L plus comprises the following
main components:
Gear motor with tilt flange, mixing tube with material hopper,
vibrator and pump unit B4-2wf / SD6-3.
The gear motor with tilt flange can also be removed from
the material hopper for transport.
Weight: 68.6 kg.
14.2 Gear motor
Fig. 8: Gear motor
Gear motor 2.2kW with tilt flange and protective tube.
Weight: 29.8 kg.
