Mixing pump RITMO L plus FC-230V Overview – Operation
Switching off RITMO L plus
2020-11-09 59
56 Switching off RITMO L plus
Fig. 117: Switching off RITMO
1. Turn the selector switch (1) to the “Zero” position
(middle position).
2. Turn the main switch (2) to the position “0”.
57 Measures to be taken if there is a risk of frost
CAUTION!
Damage due to frost!
Water that expands on freezing inside
the component can cause serious damage.
Therefore:
Carry out the following steps when the pump is
not operating and there is a danger of frost.
Fig. 118: Disconnecting the water supply
1. Remove the water hose (1) from the water inlet.
2. Remove water hose (2) from the water nozzle at the rubber
mixing zone.
Fig. 119: Removing the mixing shaft
3. Take mixing shaft (3) out of the mixing zone.
2
1
2
1
3
