Mixing pump RITMO L plus FC-230V Overview – Operation
Maintenance tasks
2020-11-09 65
5. The compressor operates free of oil and must not suck in any oil mist.
6. The ambient temperature should not exceed 45°C.
7. Be sure to store the compressor in a dry place and avoid condensation
caused by water vapours.
8. It is prohibited to use the machine in environments at risk of explosion.
Due to air compression, high temperatures are created at the compressor:
Protect against contact with hot surfaces,
or shield the area of traffic,
or attach warning notices.
If no pre-filter is mounted, the compressor filter must be cleaned weekly.
1. With the pre-filter, the filter integrated in the compressor only needs to be
cleaned very four weeks. Undo screws on the side cover.
2. Remove filter, blow it off from the inside to the outside
with compressed air (do not wash it).
3. Be sure to replace any clogged, oily, greasy or damaged
filter cartridges.
Item number for filter cartridge: 00 07 77 66
