Mixing pump RITMO L / RITMO M Overview - Operation
Remote control
2016-02-17
43
35.4 Switch off air compressor
Fig. 66: Air compressor
1. Remove connector Air compressor (1).
2. Open the air tap at the spraying gun so that the remaining
pressure can escape completely.
DANGER!
Risk of injury from discharged mortar!
Discharged mortar may lead to injuries to eyes and
face.
Attention, residual pressure.
36 Remote control
36.1 Working with the remote control
Fig. 67: Remote control
1. Remove the dummy plug from the control cabinet and connect
remote control (1).
2. The RITMO can be switched on or off using the remote control.
37 Process pasty material
37.1 Recommended accessories for pasty material
Fig. 68: Air compressor
Article number: 00 23 31 74
Description: Air compressor LK 402 IV
Fig. 69: Spraying gun
Article number: 20 19 59 00
Description: Spraying gun Ornamental and reinforcement plaster
1
1
