- Insert the spacer with the
inside chamfering facing the
insertion side.
- Place the rollers into the half-
pulley as shown in the figure.
- The covered side must rest
onto the inside thrust side of
the roller container.
- Assemble the half-pulley with
the roller contrast and the
sliding blocks.
- Insert the half-pulley on the
driving shaft.
- Insert the spacer bushing.
PGO BR-500 ENGINE
P.10-13
Automatic Transmission
