PGO BR-500 - Engine and Flywheel Cover Torque Values

1.3 TORQUE VALUE
1. Engine:
NO Locking location Q’TY Locking torque (N-m)
Remark
1 Ignition spark plug 1 12~14
2 Head fixing pins 4
Apply a preliminary
torque of 7N-m in a
Tighten by 90
0
in a cross
3 Head fixing nuts 2 10~12
4 Exhaust/Intake head fastening nuts 2 10~12
5 Head lubrication control jet 1 5~7
6 Starter motor fastening screws 2 11~13
7 Cooling fluid temperature sensor 1 10~12
8 Balance weight mass fastening screw 1 7~8.5
9 Tighten sliding block fastening screw 1 10~14
10 Phase evolution sensor fastening screw 1 3~4
11 Injector fastening screw 1 3~4
12
Valve lifting device mass stop bell
fastening screw
1 30~35
13 Intake manifold fastening screws 3 11~13
14 Tappet cover fastening screws 6 7~9
15 Throttle body fastening screws 3 11~13
16
Camshaft retaining b
racket fastening
screws
3 4~6
17 Tightener fastening screws 2 11~13
18 Head fastening screws 3 10~12
FLYWHEEL COVER
19 Flywheel fastening nut 1 115~125
20 Stator fastening screws 3 8~10
21 Blow-by recovery duct fastening screws 2 3~4
22
Screws
for fixing the free wheel on the
flywheel
6 13~15
23 Stator wiring guide bracket screws 2 3~4
P.1-4
Locking Torques
PGO BR-500 ENGINE
