NO Locking location Q’TY Locking torque (N-m)
Remark
CRANKCASE AND DRIVING SHAFT
24 Counter shaft fastening screw 1 25~29
25 Engine oil filter 1 12~16
26 Engine oil drainage cap 1 24~30
27 Crankcase coupling screws 14 11~13
28 Oil pump fastening screws 2 5~6
29 Gear screws on driving shaft 4 10~12
30
Oil pump compartment closing head
screws
2 8~10
FINAL REDUCTION
31 Hub cover screws 24~27
TRANSMISSION COVER
32 Driven pulley nut 1 92~100
33 Driving pulley nut 1 160~175
34 Transmission cover M8 fastening screws 4 23~26
35 M6 fastening screws 7 11~13
36 Anti-flapping roller fastening screw 1 17~19
37 Clutch ring nut 1 65~75
38 Internal air conveyor screws 2 7~9
39 Water pump cover screws 6 3~4
40 Outside transmission cover screws 4 7~9
41 Flywheel cover screws 14 11~13
LUBRICATION
42 Oil pump coupling screws 2 0.7~0.9
43 Oil pump fastening screws 2 5~6
P.1-5
Locking Torques
PGO BR-500 ENGINE
