- Insert the driven pulley axle cap by placing
the missing tooth in the low part at the
reference on the transmission cover.
N.B.:
Check that the air inlet and the air
outlets are totally free.
- Insert the outside plastic transmission
cover.
- Tighten the 4 fastening screws at the
prescribed torque.
Tightening torque:
Outside transmission cover screws:
7~9 Nm
PGO BR-500 ENGINE
P.10-21
Automatic Transmission
