- To remove the start-up rim
from the free wheel it is
necessary to turn it clockwise
and pull it out.
- Remove the free wheel from
the magneto flywheel by
loosening the 6 fastening
screws.
N.B.: Since the free
wheel must be removed,
it is advisable to loosen
the 6 fastening screws
in advance with the
flywheel still installed
on the driving shaft.
- The free wheel is coupled to
the flywheel with high
precision; if removal is difficult,
use 2 screws as gripping
points and as removing tools,
if required.
PGO BR-500 ENGINE
P.10-56
Flywheel and Start-up
