Ifthe values do not match, check:
- timing
- stroke-revolution sensor
- injection controller
- Start the engine.
- Select the menu on the "parameters"
function.
- Select the stroboscopic lamp control in the
conventional 4-stroke engine position (1 spark
2 revolutions).
- Check that the real values of rpm and ignition
advance match those measured by the
diagnostic tester.
PGO BR-500 ENGINE
P.10-66
Thermal Unit & timing system
