5
1. SPECIFICATIONS
LIQUID COOLING 120 mm radiator 140 mm radiator
Front Up to 240 -
Top Up to 480 Up to 420
Side (w/out HDD cages) Up to 240 -
Rear 120 140
Bottom Up to 480 Up to 280
PH-F140SP (included fans)
Speed (rpm) 1200 ± 250 rpm
Max Airow 82.1 CFM
Static Pressure 1.33mm H2O
Acoustical Noise 19 dB
CLEARANCE
Graphic card 257 mm (reservoir bracket installed)
277 mm (reservoir bracket installed w/o cover)
350 mm (no reservoir bracket)
390 mm (HDD cages in front position)
515 mm (no HDD cages)
CPU cooler 207 mm
Cable management 30 mm
Model number PH-ES813P
Warranty 5 Years
CASE SPECIFICATIONS
Dimension 250 mm x 650 mm x 600 mm (W x H x D)
Form Factor Full tower
Material(s) Aluminum faceplates, Steel chassis
Motherboard support ATX, EATX, mATX, SSI EEB
Weight 17.9 kg
Front I/O 2x USB 3.0, 2x USB 2.0, Mic, Headphone,
LED ON/OFF switch, Power Reset
Side window Yes, split-window design
EXPANSION & DRIVE BAYS
Expansion slots 8
Power supply slots 2
External 5.25” 5
Internal 3.5” 6 (2x 3HDD cages)
Internal 2.5” 12 (2x 3HDD cages + 2x doublestack SSD brackets)
( *expandable to 3x)
COOLING 120 mm fan 140 mm fan
Front 2x 2x (2x included with LED)
Top 4x 3x (1x included)
Side 2x 2x
Rear(top) 1x 1x (1x included)
Rear(bottom) 1x 1x
Bottom 4x 2x (1x included)
HDD 2x -
