25
EVOLV SHIFT XTCABLE MANAGEMENT
Secure the graphics card
1. If you have not done this during the ‘Installing Graphics Card’
chapter, please do it now.
2. The GPU can be secured with a velcro tie. Wrap the velcro tie
around the PCI-e power connectors to hold it securely in position.
* If the GPU is very short, this step is not necessary.
Secure the riser cable
1. Secure the riser cable by mounting the Riser Lock to the
motherboard on the right side of the riser cable.
The Riser Lock prevents the riser cable unintentionally detaching.
To Next Page
