Phenix Technologies HC-75C User Manual

HC 75C
2-1
SECTION 2: SPECIFICATIONS
Input: 480 VAC,
60
Hz, 400 AAC
(Note: The above current levels are based on the 30 minute duty cycle. To estimate the current draw on
the facility power at different duty cycles, multiply the above currents by the ratio of the output currents.
Ex.: An HC-75C will draw approximately 7.5 times the above current at the 1 second duty cycle.)
Output:
OUTPUT CURRENT SPECIFICATIONS
(PARALLEL CONNECTION)
DUTY CYCLE
1 Second ON /
2 Minutes OFF
1 Minute ON /
10 Minutes OFF
30 Minute ON /
30 Minutes OFF
Continuous
HC-12C
12,000 A
2,500 A
1,700 A
1,200 A
HC-20C
20,000 A
4,500 A
3,000 A
2,000 A
HC-40C
40,000 A
9,000 A
6,000 A
4,000 A
HC-75C
75,000 A
15,000 A
10,000 A
7,500 A
*Note: The HC-C Controller will impose a shutdown and a 5-minute off time if one of the above limits is exceeded.
OUTPUT CURRENT SPECIFICATIONS
(SERIES CONNECTION)
DUTY CYCLE
1 Second ON /
2 Minutes OFF
1 Minute ON /
10 Minutes OFF
30 Minute ON /
30 Minutes OFF
Continuous
HC-12C
6,000 A
1,250 A
850 A
600 A
HC-20C
10,000 A
2,250 A
1,500 A
1,000 A
HC-40C
20,000 A
4,500 A
3,000 A
2,000 A
HC-75C
37,500 A
7,500 A
5,000 A
3,750 A
*Note: The HC-C Controller will impose a shutdown and a 5-minute off time if one of the above limits is exceeded.
OUTPUT VOLTAGE SPECIFICATIONS
(OPEN CIRCUIT)
Connection /
Frequency
Series / 60Hz
Parallel / 60Hz
Series / 50Hz
Parallel / 50Hz
Number of
Taps
HC-12C
15 V
7.5 V
12.5 V
6.25 V
3
HC-20C
20 V
10 V
16.6V
8.3 V
4
HC-40C
24 V
12 V
20 V
10 V
6
HC-75C
32 V
16 V
26.6 V
13.3 V
8
