Philips 220E1SB/00 - Recommended & Spare Parts List

60
Meridian 1
16. Recommended & Spare Parts List
Recommended Parts List for 220E1SB/69
Item Location Philips 12NC PCM Codes Description Remark
1 FQ106 A34G1082AFLA1B0101 BEZEL 21.6" CMO
1 FQ106 A34G1430AFLA1B0101 BEZEL 21.5" AUO
2 FQ405 996520036036 A33G0313AFL 1L0100 KEY PAD
3 FQ004 KEPC9QP3 KEY BOARD ASSY
4 E750 750GLM216H1132M0PH PANEL M216H1-L01 C1 NB CMO
4 E750 750GLM216H1132N000 PANEL M216H1-L01 C1 NB CMO
2nd
source
4 E750 750GLU215H1043N000 PANEL M215HW01 V00G XM AUO
4 E750 750GLU215H1043M0PH PANEL M215HW01 V00G XM AUO
2nd
source
4 E750 750GLU215H1053M0PH PANEL M215HW01 V00H XM AUO
2nd
source
4 E750 750GLU215H1053N000 PANEL M215HW01 V00H XM AUO
2nd
source
4 E750 750GLU215H1063M0P PANEL M215HW01 V00J XM AUO
2nd
source
4 E750 750GLU215H1063N000 PANEL M215HW01 V00J XM AUO
2nd
source
5 FQ002 996520037004 756GQ8CB PH005
SCALER BOARD ASSY
(CBPCRNDPHQ1)
CMO
5 FQ002 756GQ9CB PH065 00
SCALER BOARD ASSY
(CBPCRNDPHQ1)
AUO
6 FQ003 PWPC8B41MQCW POWER BOARD ASSY
7 FQ105 996520036099 A34G0897AFL 3B0100 REAR COVER 21.5″
8 FQ103 996520036033 705GQ834617 21.5″ LCD STAND BASE ASS'Y
FQ307 996510014810 089G 725HAA DB D-SUB CABLE
E08907 996520036014 089G179J30N 12 FFC CABLE
FQ301 996510019911 089G410A15N IS POWER CORD WALL-OUT FOR UK
FQ205 996520036084 705GQ9CS002 CUSHION ASSY
FQ202 Q44GC085813 2D 21.6 LCD CARTON
IC902 996500036055 056G 139 3A IC PC123Y22FZ0F
T901 S80GL22T3V1 XFMR POWER 490uH TPV-PT
PT801 S80GL24T23V XFMR POWER 68uH TPV-PT VOC
IC901 996520036091 056G 379128 IC LD7576 GS SOP-8
IC801 996510018159 056G 608 12 IC TA9687GN-A-0-TR SOP-16
F901 084G 56 4W FUSE 4.0A 250V
F902 084G 56 4W FUSE 4.0A 250V
IC903 996500036054 056G 158 12 KIA431A-AT/P TO-92
U402 996520037005 100GPNMC000NT1 MCU ASSY(056G1133713) CMO
U402 100GPNAI000NT1 MCU ASSY(056G1133713) AUO
