（1）D-SUB analog R/G/B separate inputs, H/V sync separated, Composite (H+V) TTL level, SOG sync
（2）DVI digital Panel Link TMDS inputs
Ambient temperature: 0 °C - 40 °C
3. ELECTRICAL CHARACTERISTERS
Interface signals
(1) D-sub analog
Input signal :Video, Hsync, Vsync
Video :0.7 Vp-p, input impedance, 75 ohm @DC
Sync :Separate sync TTL level, input impedance 2.2K ohm terminate
:Hsync Positive/Negative
:Vsync Positive/Negative
:Composite sync TTL level, input impedance 2.2k ohm terminate
(Positive/Negative)
Sync on green video : 0.3 Vp-p Negative (Video 0.7 Vp-p Positive)
(2) DVI-D Digital
Input signal :Single TMDS link (Three channels: RX0-/+, RX1-/+, RX2-/+)
Interface
D-SUB Cable
Length :1.5m +/- 50mm
Fix with monitor when packing with transplant pin protective cover.
Connector type :D-sub male with DDC2B pin assignments
Blue connector thumb-operated jack screws
Pin assignments
PIN No. SIGNAL
1 Red
2 Green/ SOG
3 Blue
4 Sense (GND)
5 Cable Detect (GND)
6 Red GND
7 Green GND
8 Blue GND
9 DDC +3.3V or +5V
10 Logic GND
11 Sense (GND)
12 Bi-directional data
13 H/H+V sync
14 V-sync
15 Data clock
DVI Cable
