Meridian 1
Factory preset modes
• Factory modes and preset modes are defined in the enclosed timing table file
220E1 1920 1080
Timming Table-0810
2
• Video timing mode (internal firmware support)
60Hz: 480i/480p/720p/1080i/1080p
50Hz: 576i/576p/720p/1080i/1080p
Software control functions via OSD/Control adjustment functions
Please refer to following Hudson 9 OSD definitions, if any deviation, there refer to PVT exit sample.
ITEM
1 OSD DEFINITIONS
PHILIPS 220E1 OSD
Definition-081201.xl
s
Reset -
No: Exit
Yes: Auto adjustment for displaying
timing mode and recall factory preset
2 OSD LANGUAGES
H8 OSD translation -
20070425 - Final.xls
H9 new item
translation _ 2008041
8 LANGUAGES
3 OSD TREE
PHILIPS 220E1 OSD
Tree-081023.xls
4 POWER ON LOGO
1920x1080_new.
zip
Power On Logo: Power On Æ
Show up Philips logo 3 seconds Æ
Change to input signal.
This picture is reference only. The
official drawing will send out by PM.
5 AUDIO SELECTION
Stand-alone – On:
Isolate video and audio control input
Stand-alone – Off:
Integrate video and audio control
input
Mute – On: Turn off audio
Mute – Off: Turn on audio
