Service Manual 243V5LAB
12
2) Description of the On Screen Display
What is On-Screen Display (OSD)?
On-Screen Display (OSD) is a feature in all Philips LCD monitors. It allows an end user to adjust screen
performance or select functions of the monitors directly through an on-screen instruction window. A user friendly on
screen display interface is shown as below:
Basic and simple instruction on the control keys
In the OSD shown above, you can press buttons at the front bezel of the monitor to move the cursor,
and press button to confirm the choice or change.
The OSD Menu
Below is an overall view of the structure of the On-Screen Display. You can use this as a reference when you
want to work your way around the different adjustments later on.
To Next Page
