Service Manual 243V5LAB
27
5 Block Diagram
5.1 LCD Block Diagram
5.2 Panel Diagram
DC-AC inverter
AC-DC (5V/16
V)
Power Board
Main Board
715G5966M
Key board
LCD TPM236H3-HGJL02
1920 h 1080
LVDS
AC supply
90V-264V
Monitor Block Diagram
VGA/DVI
/DDC
Input
