Service Modes, Error Codes, and Fault Finding
EN 38 Q529.1E LA5.
Figure 5-19 Example UART log during SWUPG startup (Normal startup) part 2.
00 003.082 RO Flash file not found in /mnt/jffs0/ro/tvplf/tv520avi/cabinet3
00 003.082 Local flash file not found in file/cabinet3
00 003.082 RU Flash file found in /mnt/jffs0/rupg/tvplf/tv520avi/cabinet
00 003.082 Cabinet flash file : Layout version = 4 ; Content version = 16
00 003.082 Cabinet flash file : Project Id = 0 ; Branch Id = 39
00 003.082 version string: ACSTS_000.039.004.016
-1 003.182 amApp : InitDirectFB
-1 003.182 Grabbing keyboard
-1 003.182 amApp : InitSaWMan
-1 003.182 AppMan: Process added (118) [1]!
-1 003.182 AppMan: Process added (116) [2]!
-1 003.182 AppMan: Window added (0,0-1x1) [1] - 1!
00 003.304 Using cabinet option 3, name MS7_speaker_B 2K7
00 003.304 /mnt/jffs0/rupg/tvplf/cetv/pqprivate found
00 003.304 PQ private flash file : Layout version = 8 ; Content version = 0
00 003.304 PQ private flash file : Project Id = 1 ; Branch Id = 0
00 003.304 version string: PRFPV_001.000.008.000
00 003.304 /mnt/jffs0/rupg/tvplf/cetv/ambientlight found
00 003.304 Ambientlight flash file : Layout version = 3 ; Content version = 9
00 003.304 Ambientlight flash file : Project Id = 1 ; Branch Id = 0
00 003.349 version string: PRFAM_001.000.003.009i5100pow_Init
00 003.382
00 003.382 /mnt/jffs0/rupg/tvplf/cetv/pqpublic found
00 003.382 PQ public flash file : Layout version = 4 ; Content version = 2
00 003.382 PQ public flash file : Project Id = 0 ; Branch Id = 0
00 003.406 version string: PRFPB_000.000.004.002plfdmx_mdmx: DEBUG_ERROR_PRINT enabled
00 003.431 Platform Application from Apr 13 2008 22:31:30,
00 003.431 built on PC: BEQBRGBRG1TSS15 by user: beq00908
00 003.431 CCM_build_id:
00 003.431 Startup m_InitDoneBlunk: 0, m_InitDoneMain: 1
00 003.782 Check TM download idrv_DspReady_Ready
01 003.879 tvApp : entered main....
01 003.885 amApp is passing 4 arguments
01 003.890 tvApp : Param 1 = 4 Param 2 = 0
01 003.892 Tvmain: start_Init called
00 003.974 Create Thread with priority 70 (=45)
00 003.974 Create Thread with priority 70 (=45)
00 003.974 Create Thread with priority 70 (=45)
00 003.974 Create Thread with priority 70 (=45)
00 003.974 Create Thread with priority 70 (=45)
00 003.974 Create Thread with priority 70 (=45)
01 003.985 Using errlib version 0.9
00 003.988 Starting STi710x device with i2c protocol version v0.5 !
00 003.995 ST TurnOn first attemptCreate Thread with priority 70 (=45)
00 003.995 Create Thread with priority 70 (=45)
00 003.995 Create Thread with priority 70 (=45)
00 003.995 Create Thread with priority 70 (=45)
00 004.004 PNX5100: Using PCI communication for all i2c write messsages!!
00 004.007 PNX5100: Input Wdw: 1944 1104 Output Freq: 100
00 004.009 PNX5100: Input Wdw: 1944 1104 Output Freq: 120
00 004.013 Create Thread with priority 70 (=45)
00 004.015 PNX5100: Hardware Id [5100hwid]
00 004.017 Software Id [20080408]
00 004.019 BootNvm Id [ 8]
00 004.023 5100 Drv GetBootstatus via PCI : 0
00 004.038 Errlib 0.9 registered from process 164
00 004.064 TM download OK
01 004.067 (*) FusionDale/Config: Parsing config file '/etc/fusiondalerc'.
01 004.072 *--------------) FusionDale v0.1.1 (--------------*
01 004.072 (c) 2006-2007 directfb.org
01 004.072 -----------------------------------------------
01 004.078 (*) Fusion/SHM: NOT using MADV_REMOVE (2.6.18.0 < 2.6.19.2)! [0x02061200]
01 004.089 (*) Direct/Thread: Running 'Fusion Dispatch' (MESSAGING, 184)...
00 004.099 Por: 1
00 004.102 ST start up OKST SW Version: MPEG4.001.000.000.029
00 004.105 ST HW Version: MP4HW.000.000.012.002
00 004.107 5100 Drv GetBootstatus via PCI : 0
00 004.112 Firmware version 3.10 for TDA10048 succesfully downloaded
00 004.263 5100 Drv GetBootstatus via PCI : 2
00 004.265 PNX5100&&&&&& Bootstatus on 2 after 2 retries
-1 004.333 AppMan: Process added (164) [3]!
00 004.445 i5100pow_TurnOn
00 004.451 phatvEngine5100Proxy__pow_TurnOn using udma driver for autotv !!gOemRegTbl:0x3292D0
00 004.508 cetvbend_mpowon: iambl_SetState onoff = 0
-1 004.517 icplfapisetup_powN_OnTvPowerChanged for state 2
01 004.702 svspow_m.c:2922::Start Init of svspow called.MsecSinceInit: 1791999581
01 004.707 svspow_m.c:2251::Wakeup Reason is coldboot
01 004.730 svspow_m.c:2954::Quick Turn On Initiated
01 004.730 svspow_m.c:1380::Double call in InitialiseSoftware
-1 004.804 AppMan: Window added (100,100-480x300) [2] - 0!
-1 004.804 Border window attached
-1 004.804 AppMan: Switch focus to 0x5132da00 [2]
-1 004.804 AppMan: Window added (100,100-480x300) [3] - 1!
-1 004.804 Audio node attached
-1 004.813 amApp: dst setup called for 2
-1 004.820 amApp: Enabling keyboard
-1 004.823 amApp: dst setup called for 3
01 004.975 FUNCTION:hsveuins__impow_Init, LINE:216, InsStatus.Medium:255
01 004.987 MAINVIDEOWINDOW=2,sizeof(NoClearData):8,retval:0,retval1:0
00 005.060 UNBLOCK CARD
01 005.203 svspow_m.c:1526::All Subsystems inited
01 005.236 mlock patch inited
-1 005.262 HK_REQUEST_PS received for 5
-1 005.262 Ungrabbing keyboard
01 005.267 svspow_m.c:2854::REQUEST_PS for cmd: 5
00 005.270 cetvbend_mpowon: powon_TurnOn
01 005.289 <5> 5278 ZAP_END - UnBlank GCK****************Hot key received by tvApp
01 005.289 svspow_m.c:4705::HK_PREPARE_PS received for cmd = 5
01 005.289 GCK******************Hot key prepare PS received by psc
01 005.289 svspow_m.c:4049::powctl_SetPowerMode to PscPowOn
-1 005.296 Called icplfapisetup_pow_SetTvPower( 3 )
I_17662_004b.eps
110608
