Philips 43PUT6801 - Page 50

IC Data Sheets
EN 50 QM16.3A LA8.
2016-Jun-08
Table 2-1
8.4 Diagram 10-9-15 DCDC-SYSTEM-POWER2, B15, AOZ1360DIL (IC U4405)
Figure 8-5 Internal block diagram and pin configuration
20030_303.eps
Block diagram
Pinning information
IN
OUT
SET
SS
EN
5.5V
Gate Driver &
Slew Rate
Control
5V Linear
Regulator
Thermal
Shutdown
Current Limit
UVLO
Comparator
AOZ1360
C1
1µF
C2
R1
84.5kΩ
1µF
C3
1nF
AOZI360DIL
IN
IN
SS
EN
OUT
1
2
4
6
9
GND
3
OUT
8
SET
7
5
10
NC
NC
OUT
GND
