49BDL5057P
50
2
 Power-offschedule:Press[ ] or[ ] buttontosetthehourand
minuteforthedisplaytoturnoff.
Selectorleaveanempty“__”forboththehourandminuteslotifyou
donotwanttousethispower-onorpower-offschedule.
3
 Input-sourceselection:Press[ ] or[ ] buttontoselectaninput
source.Ifnoinputsourceisselected,theinputsourcewillremain
thesameaslastselected.
4
 Dateschedule:Press[ ]buttontoselectwhichdayinaweek
thisscheduleitemwillbetakeeffect,andthenpressthe[OK]
button.
5
 WhenInput-sourceselecttoUSB,enabletoaccessplaylist
setting:
4.
Foradditionalschedulesettings,press[ ],thenrepeatthesteps
above.Acheckmarkintheboxnexttothenumberoftheschedule
itemindicatesthattheselectedscheduleisineffect.
NOTES:
• Iftheschedulesoverlap,thescheduledpower-ontimetakespriority
overscheduledpower-offtime.
• Iftherearetwoscheduleitemsprogrammedforthesametime,the
highestnumberedscheduletakespriority.Forexample,ifschedule
items#1and#2bothsetthedisplaytopoweronat7:00AMandoff
at5:00PM,thenonlyscheduleitem#2willtakeeffect.
HDMI with One Wire
CECcontrol.
• {Off} -DisableCEC.(Default)
• {On}-EnableCEC.
Auto signal detection
Choosetoletthedisplaydetectanddisplayavailablesignalsources
automatically.
• {Off}-Onceasignalisconnected,itcanonlybeselectedmanually.
Iftheselectedinputisnosignal,setthedisplaytodisplaytheimage
automaticallyaccordingtothesearchorderofeachoption.
Theoptionsare:{All} / {Failover}
• {All}:DP -> HDMI1 -> HDMI2 -> DVI -> VGA->MediaPlayer->
Browser->SmartCMS->PDFReader->Custom.
• {Failover}
- Failover1:User-denedsetting.Default:HDMI1.
- Failover2:User-denedsetting.Default:HDMI1.
- Failover3:User-denedsetting.Default:HDMI1.
- Failover4:User-denedsetting.Default:HDMI1.
- Failover5:User-denedsetting.Default:HDMI1.
- Failover6:User-denedsetting.Default:HDMI1.
- Failover7:User-denedsetting.Default:HDMI1.
- Failover8:User-denedsetting.Default:HDMI1.
- Failover9:User-denedsetting.Default:HDMI1.
- Failover10:User-denedsetting.Default:HDMI1.
Power Save
Mode1[TCPoff,WOLon,autooff]
Mode2[TCPoff,WOLon,autoon/off]
Mode3[TCPon,WOLoff,autoon/off]
Mode4[TCPon,WOLoff,noautoon/off]
Powersavemodes
Mode1:DCoff->Poweroff.LED:Red.
PowerSave->Poweroff,LED:Red
Mode2:DCoff->Poweroff,LED:Red.
PowerSave->PowerSaving.LED:Orange.Canbewakeup.
Mode3:DCoff->Backlightoff,LED:Red
PowerSave->Backlightoff,LED:Orange.Canbewakeup.
Mode4:DCoff->Backlightoff,LED:Red
PowerSave->Willnotenterpowersavemode.show“nosignal”only.
RCUPower
ButtonOff
NoSignal Android
Mode1 DCOFF DCOFF boardpoweroff
Mode2 DCOFF
whensignalisback,system
wakeup
boardpoweroff
Mode3 BacklightOFF
BacklightOFF
keeppoweron
Mode4 BacklightOFF BacklightON,showno
signal
keeppoweron
FollowingtableistheactionforAndroidboardwithdifferentpowermode.
DCoff/on:presspowerbuttonbyRC
PowermodeinOSD Mode1/2 Mode3/4
DCoff shutdown 1.ThecurrentsourceAPK(such
asMediaPlayer,Broswer,PDFor
SmartCMS)willbeclosed.
2.Androidsystemwillgotothe
defaultblacklauncher.
DCon Bootup 1.Androidsystemreboots
Scalar FW Update
UpdatescalarFWbyUSB.
USB cloning
CopyPDsettingsfromonesettoanother.
Import:Copysettingsfromletodisplay
Export:CopyPDsettingsintole.
*CloneddatastoresinUSB.
*PIP/PBPstatuswillbeappliedafterACoff/onaction.
