65BDL3052E/75BDL3052E/86BDL3052E
46
7. OSD Menu
An overview of the On-Screen Display (OSD) structure is shown
below. You can use it as a reference for further adjustment of
your display.
7.1. Navigating the OSD Menu
7.1.1. Navigating the OSD menu using the remote
control
1. Press [ ] button on the remote control to display the OSD
menu.
2. Press [ ] or [ ] button to select the item to adjust.
3. Press [OK] or [ ] button to enter the submenu.
4. In the submenu, press [ ] or [ ] button to toggle between
items, press [ ]
or [ ] button to adjust the settings. If
there is a submenu, press [OK] or [ ] button to enter the
submenu.
5. Press [ ] button to return to the previous menu, or press
[ ]button to exit from the OSD menu.
7.1.2. Navigating the OSD menu using the
display’s control buttons
1. Press [MENU] button to display the OSD menu.
2. Press [ ] or [ ] button to select the item to adjust.
3. Press [ ] button to enter the submenu.
4. In the submenu, press [ ] or [ ] button to toggle between
items, press [ ] or [ ] button to adjust settings. If there is a
submenu, press [ ] button to enter the submenu.
5. Press [MENU] button to return to the previous menu, or
keep pressing [MENU] button to exit from the OSD menu.
7.2. OSD Menu Overview
7.2.1. Picture menu
Screen
Audio
Con�guration 1
Con�guration 2
Advanced option
Android Settings
Brightness
Contrast
Sharpness
Black Level
Tint
Color
Noise reduction
Gamma selection
Color temperature
Color control
Smart power
Overscan
Picture reset
80
50
10
50
50
55
Off
Native
Native
Action
Off
Off
Action
Brightness
Adjust the brightness of this display’s backlight.
Contrast
Adjust the contrast ratio for the input signal.
Note: VIDEO source only
Sharpness
This function is digitally capable to keep a distinct image at all
times.
Adjust the sharpness of the picture for each picture mode.
Note: VIDEO source only
Black level
Adjust the image brightness for the background.
Note: VIDEO source only. sRGB picture mode is standard and
cannot be changed.
Tint (Hue)
Adjust the tint of the screen.
Press + button the esh tone color becomes greenish.
Press - button the esh tone color becomes purplish.
Note: VIDEO source only
Color (Saturation)
Adjust the color of the screen.
Press + button to increase color depth.
Press - button to decrease color depth.
Note: VIDEO source only
Noise reduction
Adjust the noise reduction level.
Note: VIDEO source only
Gamma selection
Select a display gamma. It refers to the brightness performance
curve of signal input. Choose from {Native} / {2.2} / {2.4} / {s
gamma} / {D-image}.
Note: VIDEO source only. sRGB picture mode is standard and
cannot be changed.
