Philips CED232 - 3 Install the Car Audio; Connect Wires

8 EN
3 Install the car
audio
These instructions are for a typical installation.
However, if your car has different requirements,
make the corresponding adjustment. If you have
any questions regarding installation kits, consult
your Philips car audio dealer.
Caution
• This unit is designed for negative ground (earth) 12 V
DC operation only.
• Always install this unit in the car dashboard. Other
locations can be dangerous as the rear of the unit heats
up during use.
• To avoid short-circuit: before you connect, ensure that
the ignition is off.
• Ensure that you connect the yellow and red power
supply leads after all other leads are connected.
• Ensure that all loose leads are insulated with electrical
tape.
• Ensure that the leads do not get caught under screws
orin parts that will move (e.g. seat rail).
• Ensure that all ground (earth) leads are run to a
common ground (earth) point.
• Use only the supplied mounting hardware for a safe
and secure installation.
• Improperfusescancausedamageorre.Whenyou
need to change the fuse, consult a professional.
These instructions are for a typical installation.
However, if your car has different requirements,
make the adjustment accordingly. If you have
any question regarding installation kits, consult
your local retailer.
Note
• This system is designed for negative ground (earth) 12V
DC operation only.
• Always install this system in the car dashboard. Other
locations can be dangerous as the rear of the system
heats up during use.
• To avoid short-circuit: before you connect, make sure
that the ignition is off.
• Make sure that you connect the yellow and red power
supply leads after all other leads are connected.
• Make sure that all loose leads are insulated with
electrical tape.
• Make sure that the leads do not get caught under
screws iron parts that will move (e.g. seat rail).
• Make sure that all ground (earth) leads are run to a
common ground (earth) point.
• Use only the supplied mounting hardware for a safe
and secure installation.
• Improperfusescancausedamageorre.Whenyou
need to change the fuse, consult a professional.
• When you connect other devices to this system, make
sure that the rating of the car circuit is higher than the
total fuse value of all the connected devices.
• Never connect speaker wires to the metal body or
chassis of the car.
• Never connect speaker wires with stripes to one
another.
Connect wires
Note
• To enjoy video on an external screen, make sure that
you have correctly connected the system to the screen
as indicated below in step 2.
• Make sure that all loose leads are insulated with
electrical tape.
• Consult a professional to connect wires as instructed
below.
1 Check the car's wiring carefully and
connect them to the the ISO male
connectors.
