38
DELL P1230 M25P
Go to cover page
Spare Parts List
Model : 6L3P10/76
Mechanical
0001 313812754391 FRONT CABINET ASSY-MG
0002 313812754401 BACK COVER ASSY-MG
0003 313812754421 PEDESTAL ASSY-MG
0041 313810461681 FRONT CABINET-MG
0042 313810461731 BACK COVER-MG
0043 313810461881 REAR COVER-MG
0044 313810461901 BASE-MG
0045 313810461691 FUNCTION BUTTON-SILVER
0046 313810461711 POWER HOLDER
0047 313810461701 POWER BUTTON-SILVER
0048 313810461721 LENS -POWER
0053 313810461891 SWIVEL-MG
0056 313810449481 FOOT RUBBER
0128 313810445691 HOUSING COVER
Various
0450 313810662731 CARTON
0451 313810662741 CUSHION-TOP FRONT
0452 313810662751 CUSHION-TOP REAR
0453 313810662761 CUSHION-BOTTOM
0454 313810663051 P.E. BAG
CRT
1051 932220343682 CRT M51LVT42X71A (MITJ) B
Main PCB
1160 313817867421 MAIN PCB ASSY(DELL)
1161 313817867431 VIDEO BOARD ASSY(DELL)
1162 313817867441 TERMIAL PCB ASSY(DELL)
1163 313817867451 CONTROL PCB ASSY(DELL)
1164 313817867291 DRIVER PCB ASSY
1165 313817867301 MHR PCB ASSY
Accessories
0601 313811706561 E-D.F.U. ASSY
0616 313811706001 HEX CODE OF F/W (NO MATL REQ)
1053 313812874901 MAINSCORD
1054 313819870591 CORD SUB-D 15/1M8/15 D-SUB BK
Others
0222 313811578981 LABEL-CPU(DRIVER)
1052 313818808521 ALL CHASSIS KITS(DELL)
1055 313817861921 D&CORNER COIL(202P4)
1061 313818873431 COIL DEGAUS TDC196
1063 313818873441 COIL CORNER TDC200 A
1064 313818873451 COIL CORNER TDC200
1103 242208600208 FUSE 5X20 HT 4A 250V IEC B
1190 243813200141 RELAY 2P 12V 5A OSA-SS Y
1191 241112102038 RELAY 2P 12V 5A OMISS212L B
1207 243854300061 RES XTL 12MHZ 30P HC49/U B
1211 313817867521 MTP ASSY
1265 313817867481 EEPROM ASSY(DELL)
1274 313817853361 CERC CAP+CORE ASSY-2765
1301 243854300064 RES XTL 12MHZ 32P HC49/S B
1796 313816879171 FERRITE CORE C8BRH 3.5X3.2X1
1797 313816879171 FERRITE CORE C8BRH 3.5X3.2X1
1798 313816879171 FERRITE CORE C8BRH 3.5X3.2X1
1799 313816879171 FERRITE CORE C8BRH 3.5X3.2X1
1160 313817867421 MAIN PCB ASSY(DELL)
4444 313810610349 CD ROM - SERVICE MANUAL
4444 313810610350 SERVICE MANUAL
1160 313817867421MAIN PCB ASSY(DELL)
2101 203831000007 CAP MPP 275V S 470N PM10 B
2102 203831000007 CAP MPP 275V S 470N PM10 B
2103 202203100085 ELCAP HP 450V S 330U PM20 B
2104 203830200305 CAP MPOL 400V S 33N PM5 B
2106 202055490139 CERSAF NSB 250V S 4N7 PM20 B
2108 202055490139 CERSAF NSB 250V S 4N7 PM20 B
2111 202203100083 ELCAP KM 25V S 150U PM20 A
2115 223858015627 CER2 0805 X7R 50V 2N2 PM10 R
2120 203830200167 CAP MPOL 400V S 10N PM10 B
2122 223886115561 CER1 0805 NP0 50V 560P PM5 R
2123 223891015649 CER2 0805 X7R 25V 100N PM10 R
2124 202055790153 CER2 DC B 500V S 2N2 PM10 A
2126 202055890556 CERHDT RR 1KV S 680P PM10 A
2127 203830100208 CAP PP PPN 250V S 47N PM5 B
2128 223886115331 CER1 0805 NP0 50V 330P PM5 R
2129 202055490127 CERSAF NSA 250V S 2N2 PM20 B
2130 202055490149 CERSAF NSA 250V S 3N3 PM20 B
2131 202203100066 ELCAP KM 350V S 100U PM20 B
2133 202203100067 ELCAP GL 100V S 220U PM20 B
2134 202203100225 ELCAP GL 25V S 2200U PM20 B
2135 202203100223 ELCAP GL 25V S 1000U PM20 B
2137 202203100223 ELCAP GL 25V S 1000U PM20 B
2139 202202000706 ELCAP GS 16V S 2200U PM20 B
2143 203803527203 ELCAP KM 16V S 220U PM20 A
2154 223886115101 CER1 0805 NP0 50V 100P PM5 R
2155 222291019856 CER2 0805 Y5V 25V 330N P8020 R
2160 202202000833 ELCAP GS 10V S 100U PM20 A
2162 202202000836 ELCAP GS 50V S 1U PM20 A
2163 202202000938 ELCAP GS 25V S 470U PM20 A
2171 223858015645 CER2 0805 X7R 50V 47N PM10 R
2172 203830250089 CAP MPOL 100V S 10N PM10 A
2173 203803527501 ELCAP KM 50V S 10U PM20 A
2174 203830250095 CAP MPOL 100V S 100N PM10 A
2301 202202000805 ELCAP GS 50V S 2U2 PM20 A
2302 202202000805 ELCAP GS 50V S 2U2 PM20 A
2303 203830250212 CAP MPOL 100V S 100N PM5 A
2304 203803521206 ELCAP GS 16V S 47U PM20 A
2305 203803521218 ELCAP GS 16V S 470U PM20 A
2306 203803521501 ELCAP GS 50V S 10U PM20 A
2307 223886115229 CER1 0805 NP0 50V 22P PM5 R
2308 202202000805 ELCAP GS 50V S 2U2 PM20 A
2309 202202000805 ELCAP GS 50V S 2U2 PM20 A
2310 203830250094 CAP MPOL 100V S 47N PM10 A
2311 203830250094 CAP MPOL 100V S 47N PM10 A
2312 202055290594 CER1 DC NP0 50V S 22P PM5 A
2313 202055290594 CER1 DC NP0 50V S 22P PM5 A
2314 223886115229 CER1 0805 NP0 50V 22P PM5 R
2315 223858015636 CER2 0805 X7R 50V 10N PM10 R
2316 203830250094 CAP MPOL 100V S 47N PM10 A
2336 203830250095 CAP MPOL 100V S 100N PM10 A
2337 223886115229 CER1 0805 NP0 50V 22P PM5 R
2338 223886115229 CER1 0805 NP0 50V 22P PM5 R
2361 203803527204 ELCAP KM 16V S 330U PM20 A
2362 203803527202 ELCAP KM 16V S 100U PM20 A
2391 223891015649 CER2 0805 X7R 25V 100N PM10 R
2392 223886115101 CER1 0805 NP0 50V 100P PM5 R
2401 203830250095 CAP MPOL 100V S 100N PM10 A
2421 203830250095 CAP MPOL 100V S 100N PM10 A
2422 203830250121 CAP MPOL 100V S 150N PM10 A
2423 202055290607 CER1 DC NP0 50V S 220P PM5 A
2424 223891015649 CER2 0805 X7R 25V 100N PM10 R
2425 202203100097 ELCAP KM 16V S 1500U PM20 B
2426 202055290594 CER1 DC NP0 50V S 22P PM5 A
2431 203830250212 CAP MPOL 100V S 100N PM5 A
2432 203830150186 CAP PP PPN 100V S 8N2 PM5 A
2433 203830250218 CAP MPOL 100V S 10N PM2 A
2434 203830150147 CAP PP PPN 100V S 1N8 PM5 A
2435 203830150186 CAP PP PPN 100V S 8N2 PM5 A
2441 203830150191 CAP PP PPN 100V S 3N3 PM2 A
2442 223858015629 CER2 0805 X7R 50V 3N3 PM10 R
2443 223858015645 CER2 0805 X7R 50V 47N PM10 R
2445 203803521206 ELCAP GS 16V S 47U PM20 A
2446 203830250099 CAP MPOL 100V S 470N PM10 A
2456 203803521206 ELCAP GS 16V S 47U PM20 A
2461 203830100104 CAP PP PPN 250V S 220N PM5 B
2462 223886115221 CER1 0805 NP0 50V 220P PM5 R
2463 203803521206 ELCAP GS 16V S 47U PM20 A
2464 223858015633 CER2 0805 X7R 50V 5N6 PM10 R
2491 203830250095 CAP MPOL 100V S 100N PM10 A
2492 223886115339 CER1 0805 NP0 50V 33P PM5 R
2493 223886115339 CER1 0805 NP0 50V 33P PM5 R
2501 202233300303 CAP MPP 250V S 470N PM5 B
2502 203803522801 ELCAP BP NK 160V S 1U PM20 A
2503 203830250095 CAP MPOL 100V S 100N PM10 A
2504 222237590705 CAP PP-MPP 2K5V S 3N3 PM5 B
2506 202055890561 CERHDT RR 2KV S 220P PM10 A
2507 202055890561 CERHDT RR 2KV S 220P PM10 A
2515 202055890557 CERHDT RR 1KV S 1N PM10 A
2516 203830250099 CAP MPOL 100V S 470N PM10 A
2518 203830250095 CAP MPOL 100V S 100N PM10 A
2519 203830250095 CAP MPOL 100V S 100N PM10 A
2520 203830250095 CAP MPOL 100V S 100N PM10 A
2541 203803522801 ELCAP BP NK 160V S 1U PM20 A
2542 203830100117 CAP MPP 100V S 1U PM10 B
2543 202203100066 ELCAP KM 350V S 100U PM20 B
2544 202055890562 CERHDT RR 2KV S 330P PM10 A
2545 223891015649 CER2 0805 X7R 25V 100N PM10 R
2546 223891015649 CER2 0805 X7R 25V 100N PM10 R
2551 203803527303 ELCAP KM 25V S 47U PM20 A
2552 203803527303 ELCAP KM 25V S 47U PM20 A
2553 202233300301 CAP PP PPN 400V S 91N PM5 B
2554 203830100201 CAP PP PPN 400V S 82N PM5 B
2555 203830250095 CAP MPOL 100V S 100N PM10 A
2556 223891015649 CER2 0805 X7R 25V 100N PM10 R
2566 203803527501 ELCAP KM 50V S 10U PM20 A
2567 202203100221 ELCAP KM 25V S 470U PM20 B
2568 203803521405 ELCAP GS 35V S 100U PM20 A
2569 202055290607 CER1 DC NP0 50V S 220P PM5 A
2576 203830250093 CAP MPOL 100V S 22N PM10 A
2577 202203100221 ELCAP KM 25V S 470U PM20 B
2578 203830250095 CAP MPOL 100V S 100N PM10 A
2579 203830250099 CAP MPOL 100V S 470N PM10 A
2586 203830250212 CAP MPOL 100V S 100N PM5 A
2588 203830250095 CAP MPOL 100V S 100N PM10 A
2589 203830250095 CAP MPOL 100V S 100N PM10 A
2601 202055890661 CER1 DC SL 2KV S 68P PM5 A
2602 202055890662 CER1 DC SL 2KV S 56P PM5 A
2603 202055890557 CERHDT RR 1KV S 1N PM10 A
